MNF532

MNF532024DC

Product Description

Solenoid valve NAMUR
with combined 5/2- and 3/2- ways



– Piston spool solenoid valve NAMUR, indirectly operated, 5/2 and 3/2 way function,
magnet coil and connector with exit M16 for cable diameter 5-6mm
– Easy change over from 5/2 to 3/2 way function through innovative reversing sealing
– Air spring return
– Standard self-locking brass manual override
– Body anodised aluminum, with minimal external dimensions
– NAMUR adapter plate PA6-30% fiber glass, with exhaust air feedback circuit
– Stainless steel piston AISI 303, Sealings NBR, Stainless steel screws AISI 304
– Media: Cleaned and lubricated or non-lubricated compressed air with
a quality level 5 according to ISO 8573-1
– Application: Control of spring return and double acting
pneumatic actuators with NAMUR interface



Technical features:

Air entry: G1/4″
Dimension: 5,5mm
Air pressure: 2-10 bar
Temperature: -20°C — +50°C
Enclosure: IP65
Voltage:
DC:
12V, 24V, 110V
AC: 24V, 48V, 115V, 230V
Air flow: 950l / min
